Chipset

Intel® HM86

BIOS

AMI 32Mbit, Support Diskless Boot, Wake on Lan, Power-on Boot, Watchdog, etc.

Memory

Capacity

4GB SO-DIMM DDR3L 1600 MHz memory ,   Max.8GB

Storage

SATA Interface

MINI PCIE

2.5〞5400rpm 500G

1xMini PCIE

Display

Graphics

Output

CPU Integrated HD Graphics

VGA+HDMI+DP single/dual display (synchronous/asynchronous display)

1 × VGA   （Max. resolution: 1920×1080）

1 ×HDMI   （Max. resolution: 1920×1080）

1 ×   DP   （Max. resolution: 1920x1080）

Ethernet

Lan

WIFI

1 × RTL8111E   10/100/1000M（RJ45 LAN）

1 x WIFI Module support 802.11b/g/n （Mini PCIE half card）

I/O

USB 3.0

USB 2.0

Power button

Reset

COM

OPS Interface

LED Light

DC JACK

Audio

4x USB3.0

2× USB2.0

1 × power button

1 × Reset

1 × COM (optional)

1 × OPS Interface (80 pins)

1 x Power LED & 1 x HDD LED

1 × DC JACK

1 × LINE-OUT & MIC-IN, Integrated 6 sound channels ALC662 audio card chip

Power

Input

Rated Power

DC   12~19V

60W

Watchdog

Output

Interval

Interrupts, system restart

L255 time interval

Physical

Parameter

Dimension

180mm (L) x 195mm (W) x 42mm (H)

Condition

Temperature

Humidity

Work Temp.: 0°C ~50°C, Storage Temp.: -20~70°C

5%~90% No condensation

Operating System

Vision

Windows 10/Windows 7 / windows8 / Linux
