Chipset

Intel® SOC

BIOS

AMI 32Mbit, Support Diskless Boot, Wake on Lan, Power-on Boot, Watchdog, etc.

Memory

Capacity

4GB SO-DIMM DDR4 2400MHz memory, Max.16GB

Storage

SATA Interface

MINI PCIE

2.5〞5400rpm 500G

1xMini PCIE

1XM.2 2242 NGFF

Display

Graphics

Output

Integrated Graphics

HDMI+HDMI+DP (Single / Dual Display, Synchronous / Asynchronous Display)

1 × HDMI   （Max. Resolution: 3840x2160）

1 ×   DP   （Max. Resolution: 3840x2160）

Ethernet

Lan

WIFI

1 × RTL8111E   10/100/1000M（Max. 2 x RJ45 Lan）

1 x WIFI Module support 802.11b/g/n （Mini PCIE half card）

I/O

USB 3.0

USB 2.0

Power button

Reset

One key recovery

OPS Interface

COM

LED Light

DC JACK

Audio

4 x USB 3.0

2 × USB 2.0

1 × Power button

1 × Reset button

1 x one key covery button

1 × OPS Interface (80 pins)

1 x COM (optional)

1 x Power LED & 1 x HDD   LED

1 × DC JACK

1 × LINE-OUT & MIC-IN, Integrated 6 sound channels ALC662 audio card chip

Power

Input

Rated Power

DC   12~19V

45W

Watchdog

Output

Interval

Interrupts, system restart

L255 time interval

Physical

Parameter

Dimension

180mm (L) x 119mm (W) x 30mm (H)

Condition

Temperature

Humidity

Work Temp.: 0°C ~50°C, Storage Temp.: -20~70°C

5%~90% No condensation

Operating System

Vision

Windows 10 / Linux

AOS-SOJ4145C

Intel Celeron J4105    1.50 GHz    4G Memory    500G HDD

AOS-SOJ5045C

   Intel Pentium J5005   1.50 GHz    4G Memory    500G HDD

AOS-SON4045C

   Intel Celeron N4000   1.10 GHz    4G Memory    500G HDD

AOS-SON4145C

   Intel Pentium N4100   1.10 GHz    4G Memory    500G HDD
