AOS-SOHAUF41SEY
Product introduction£º
Specification parameter
processor
| CPU | Intel Alderlake-u I5 1240P 1.7GHZ 12 cores 16 threads (I3 1220P 1.5G 10 core 12 threads /I5 1240P 12 core 16 threads (1235U 1.3G10 core 12 threads /12450H 2.0G8 core 12 threads /13420H Rui 4.6G 8 core 12 threads)/I7 1260P 2.1 12 core 16 threads (1360P Rui frequency 5G 12 core 16 threads /13700H Rui frequency 5G 14 core 20 threads)/I9 13900H Rui Frequency 5.4G 14 core 20 threads) |
chipset | Intel® SOC | |
BIOS | AMI 32Mbit£¬Supports disk-free startup, network wake up, power-on, and watchdog functions | |
Internal memory | capacity | 4GB SO-DIMM 2xDDR4 2400 MHz memory , Max.32GB |
store | SATA interface M.2 | 2.5¨•HDD(Optional) 1Xm.2 NGFF/NVME |
reveal | Collective display Exportation
PCIEX4 | CPU integrated Graphics for 12th Gen /Iris Xe HDMI+HDMI +DP+DP Single display, double display, three display, four display (same/asynchronous/splicing display) 1 ¡ÁHDMI2.0 (Max support resolution: 4096x2304 60HZ) 1X DP1.4 (supported resolution: 4096*2304, 5120*2880, 7680*4320 60HZ)4K/5K/8K
1X PCIEX4(external independent graphics card) |
network | Chip WIFI MINI PCIE | 1 x 10/100/1000M (Dual network ports optional) 1 x WIFI Module support 802.11b/g/n (M.2 PCIE half card) 1 x MINI PCIE(4G communication module) |
I/O | USB 3.1 USB 3.0 Type-c HDMI IN Power button OPS interface COM LED light One-button restore DC JACK Audio frequency | 3x USB3.1 3¡Á USB2.0 1x type-c 1x HDMI IN£¨4K capture£© 1 ¡Á power button 1 x OPS interface (80pin) 1 x RS232 COM (optional) 1x power indicator &1x hard disk indicator 1 x hardware system restore in one touch 1 ¡Á DC JACK 1 ¡Á LINE-OUT & MIC-IN |
Power source | input Rated power consumption | DC 12~19V 60W |
Guard dog | exportation interval | The system restarts. Procedure 255 level timing interval |
Physical parameter | dimension | 180mm (L) x 195mm (W)x30mm(H) |
environment | temperature humidness | Operating temperature: 0¡ãC ~50¡ãC Storage temperature: -20 ¡ãC ~70¡ãC 5% to 90% no condensation |
Operating system | edition | Windows 10/Windows 11 / Linux |
Ordering information
Sales model | Instructions |
AOS-SOHAUI41SEY | Intel I3 1220P 1.5GHz 4Gmemory 128G SSD |
AOS-SOHAUF41SEY | Intel I5 1235U 1.3GHz 4Gmemory 128G SSD Intel I5 1240P 1.7GHz 4Gmemory 128G SSD Intel I5 12450H 2.0GHz 4Gmemory 128G SSD |
AOS-SOHAUJ41SEY | Intel I7 1260P 2.1GHz 4Gmemory 128G SSD Intel I7 1360P 5.0GHz 4Gmemory 128G SSD Intel I7 13700H 5.4GHz 4Gmemory 128G SSD |
Dimension drawing
Application field
It is suitable for medical (ultrasound/endoscopy /DR/CT/MR/IVD), education, government affairs and other fields.
