AOS-M2BW31M
Product introduction£º
Product Description
2.5-inch industrial motherboard (100¡Á72mm)
Intel Braswell J3160/N3160 CPU (quad-core, quad-thread), 6W
4GB DDR3 onboard memory
Supports DP/HDMI+LVDS, synchronous or asynchronous display
2 USB 3.0, 2 USB 2.0, 1 GPIO
2 COM ports, optional RS485
1 full-size Mini-PCIe port (supports PCIe and USB devices)
Supports wake-on-LAN, power-on, watchdog timer, etc.
Compliant with CE, FCC, and ROHS regulations
Specifications and parameters
´¦ÀíÆ÷processor | CPU | Intel Braswell J3160/N3160 CPU |
Chipset | Intel® SOC | |
BIOS | AMI 32Mbit£¬Support diskless boot, network wake-up, power-on boot, watchdog and other functions | |
Memory | Capacity | Default DDR3 4GB soldered-down memory |
Storage | M-SATA Interface N-SATA Interface | 1¡ÁSATA 3.0 1¡ÁM-SATA |
Display | Chipset Output | CPU integrated HD Graphics 1 x HDMI (maximum resolution: 3840x2160 60Hz) 1¡ÁLVDS Synchronous or asynchronous display |
ÍøÂçNetwork | Chip Wake on LAN | 1 ¡Á Intel i211AT 10/100/1000M£¨RJ45 LAN£© Supports network wake-up, PXE functionality |
I/O | HDMI USB 3.0 RJ45 DC JACK | 1 ¡Á HDMI 2 ¡Á USB3.0 1¡Á RJ45 Ethernet port 1*DCIN DC input |
Onboard functions | COM port USB2.0 M.2 SATA AUDIO expansion slot | 2¡ÁCOM 2¡ÁUSB2.0 1¡ÁM.2 1¡ÁSATA 1¡ÁAUDIO 1¡ÁMini PCIe£¨Full length or half length) |
Power supply | Input Power Rating | DC JACK 9V-14V 60W |
Watchdog timer | Output Interval | Interrupt, system restart 255 level timer intervals |
Physical parameters | Dimensions | 100mm (L) x 72mm (W) |
Environment | Temperature Humidity | Operating Temperature: 0¡ãC to 50¡ãC Storage Temperature: -20¡ãC to 70¡ãC 5% to 90% non-condensing |
Operating system | Version | Windows 10/Windows 11/ Linux |
Order information
sales model | explain |
AOS-M2BW31M-1 | CPU£ºJ3160 |
AOS-M2BW31M-2 | CPU£ºN3160 |
Display diagram
application areas
Suitable for education, restaurants, hotels, shopping malls, company meetings,government transparency, and other fields.
