Specification List

CPU

RK3588S Quad-core Cortex-A76 and Quad-core Cortex-A55, up to 2.4GHz

DDR

LPDDR4 4GB (8GB|16GB|32GB optional)

Storage

The default comes with an 32GB EMMC NAND chip that can scale up to 256GB

LVDS

30-pin industry-standard dual LVDS supporting VESA/JEITA format up to 1080P output

MIPI-DSI

31-Pin FPC MIPI-DSI display port supporting up to 1920x1200

HDMI Output

1 HDMI 2.1 standard display interface supports up to 8K output

HDMI Input

HDMI 2.0/1.4b±ê×¼ÊäÈë½Ó¿Ú£¬×î¸ßÖ§³Ö1080p@60Hz

HDMI 2.0/1.4b standard video input interface, up to 1080p@60Hz

EDP

30ÕëÐÐÒµ±ê×¼FPC EDP½Ó¿Ú£¬Ö§³Ö1~2ͨµÀģʽ£¬×î¸ßÖ§³Ö1080PÊä³ö

30-pin common FPC EDP supporting 1~2 lanes format up to 1080P output

HP/MIC

Ö§³ÖÃÀ±ê4¶Î¶úÂóÒ»Ìå3.5mm²å×ù£¨×ó-ÓÒ-µØ-Âó¿Ë£©

Support CTIA 4-pole HP/MIC socket (Left-Right-GND-Mic)

Line Output

Ö§³Ö±ê×¼×óÓÒÉùµÀÏß·Êä³ö£¨ÅÅÕë½Ó¿Ú£©

Support standard left and right channel line output (pin header)

Amplifier output

8Å·¡¤6W˫·ÒôƵ¹¦·ÅÊä³ö

8 Ohm 6W Dual Audio Amplifier Output

MIC Input

µ¥¶ËMICÊäÈ루ÅÅÕë½Ó¿Ú£©

Single-End MIC input (pin header)

Line Input

Ö§³Ö±ê×¼×óÓÒÉùµÀÏß·ÊäÈ루ÅÅÕë½Ó¿Ú£©

Support standard left and right channel line input (pin header)

USB Interface

2¸öºá²å½Ó¿Ú£¨USB Host 2.0x1ºÍUSB OTG 3.0x1£©£¬1¸öTYPE-C²å×ù£¬6¸öÄÚÖÃÅÅÕ루USB Hub 2.0x4¡¢USB Host 2.0x1ºÍUSB OTG 3.0ÅÅÕëx1¸´Óã©

2 horizontal connectors (USB Host 2.0x1 and USB OTG 3.0x1), 1 TYPE-C socket, 6 pin headers (USB Hub 2.0x6, USB Host 2.0x1 and USB OTG 3.0 pinx1 reuse)

Serial Port

2¸öTTL/RS-232/RS-485¼æÈÝÄÚÖã¬4¸öTTL/RS-232¼æÈÝÄÚÖÃ

2 TTL/RS-232/RS-485 compatible, 4 TTL/RS-232 compatible

Micro SD Card

×Ôµ¯Ê½TF¿¨²å×ù£¬×î¸ßÖ§³Ö256GB TF¿¨

Self-elastic micro SD card socket, up to 256GB capacity

Camera

Ö§³Ö800ÍòµÄÏñËØÒÔÄÚUSBÉãÏñÍ·

Support USB camera within 8 million pixels

WIFI

ÄÚÖøßÐÔÄÜSDIO½Ó¿ÚWiFi6Ä£¿é£¬Ö§³ÖIEEE 802.11 a/b/g/n/ac/ax£¬Ä¬ÈÏÅäÖÃ˫ƵWIFI

Built-in high performance SDIO interface WiFi6 module, support IEEE 802.11 a/b/g/n/ac/ax, dual-band is configured by default.

Bluetooth

Built-in high performance serial interface BT module with support for V2.1+EDR/BT v3.0/BT v3.0+HS/BT v4.0/BT v5.0

Ethernet

1 port 10/100/1000M Adaptive Ethernet RJ45 connector + 4-Pin POE header

PCIE 4G/5G

ÐÐÒµ±ê×¼PCIE 4G/5GÄ£¿é½Ó¿Ú

Industry standard m-PCIE 4G module interface

Backlight Control

1 port Industry standard LCD backlight control header, support for backlight switch and brightness adjustment

ºìÍâÒ£¿Ø

Infrared RC

±ê×¼ºìÍâ½ÓÊÕÅÅÕë½Ó¿Ú

Standard infrared receiver pin header

GPIOÐźÅ

GPIO Signals

×î¸ß8·GPIOÐźţ¬¿ÉÀ©Õ¹GPIO°´¼üºÍ/»ò3.3VÊäÈë/Êä³ö

Up to 8-way GPIO signals for such as GPIO buttons and/or 3.3V digital input/output

I2C×ÜÏß

I2C Bus

I2CÅÅÕëºÍFPC½Ó¿Ú£¬¿ÉÀ©Õ¹I2CµçÈÝÆÁµÈ

I2C pin header and FPC for I2C capacitive screen and etc

CLKʱÖÓ

CLK Clock

1·CLKOͬԴʱÖÓÐźÅ

1 CLKO homologous clock signal

M.2 PCIE NVME½Ó¿Ú

M.2 PCIE NVME Port

1·M.2 PCIE NVME SSD²å×ù£¬Ö§³ÖM.2 NVME 2280µÄ¹Ì̬ӲÅÌ

1 Supports M.2 PCIE NVME SSDS, support for M.2 NVME 2280 SSDS

CAN×ÜÏß

CAN Bus

1·CANÅÅÕë½Ó¿Ú£¬¿ÉÀ©Õ¹CAN×ÜÏßÍâÉè

1 CAN pin headers for CAN Bus peripherals

ʵʱʱÖÓ

Real Time Clock

³¬µÍ¹¦ºÄRTCµç·£¨´øCR1220Ŧ¿Ûµç³Ø£©£¬²¢¿ÉÖ§³Ö¶¨Ê±¿ª¹Ø»ú

Ultra-low-power RTC circuit (CR1220 battery) with timer and alarm functionalities

ָʾµÆ

LED Indicator

ºìÉ«´ý»úָʾºÍÂÌÉ«¹¤×÷ָʾµÆ

Red LED indicator for standby and green LED indicator for running

°´¼ü

Buttons

ÉÕ¼¼ü£¨RECOVERY£©ºÍµçÔ´¼ü

Recovery mode button and power switch button

µçÔ´ÊäÈë

DC Input

Ö§³Ö9~15V¿íµçѹֱÁ÷µçÔ´ÊäÈë

Supports 9~15V wide voltage DC power input

»·¾³ÒªÇó

Ambient Requirement

¹¤×÷ζÈ-20¡ãC ~ 70¡ãC£¬¹¤×÷ʪ¶È0%~95%£¨²»½á¶£©

Working temperature -20¡ãC ~ 70¡ãC, working humidity 0%~95% (non-condensing)

ÎïÀí³ß´ç

Physical Size

³¤*¿í*¸ß£¨135mm*93mm*9mm£©£¬PCBÕýÃæ¸ß¶È7.5mm

Length*Width*Height (135mm*93mm*9mm), PCB top side height 7.5mm

²Ù×÷ϵͳ

Operating System

ÍƼö°²×¿12.0£¬¿ÉÑ¡Linux Buildroot/Debian 11/Ubuntu-20.04

Recommended Android 12.0, Linux Buildroot/Debian 11/Ubuntu-20.04 optional
