Chipset

SOC

memory

capacity

2GB SO-DIMM DDR3 1333 MHz memory , Max.4GB

storage

EMMC

TF Card

M.2

SATA

16G, Max.64GB

Support for 64G

                                128G support

                                Supports 3.5-inch 500-2TB HDD

display

output

HDMI single display ( support HDMI plus HDMI dual display, up to 3840 x 2160).

1 ¡ÁHDMI (maximum support resolution:1920x1080).

function

MINI PCIE

COM port

Power amplifier

1X MINI PCIE (optional 3G/4G and MSATA).

2X RS232-1X RS485 (optional). )

5W(optional).

Internet

Internet

WIFI

1 ¡Á 10/100/1000M£¨RJ45 LAN£©

1 ¡Á 10/100/1000M(Fibre Network) is optional

1 x AP6356S WIFI2.4G/5G Dual Mode (optional) or WIFI6 optional )

I/O

USB 2.0

USB 3.0

IR

Power button

Reset

LED light

audio

2¡Á USB2.0(up to 3 groups supported).

1x USB3.0(optional).

1X IR infrared (optional).

1 ¡Á power button

1 ¡Á upgrade

1 x LED indicator light

1 ¡Á LINE-OUT & MIC-IN

power supply

input

Rated power consumption

AC 220V

500

The physical parameters

size

430mm (L) x 302mm (W)x44mm(H)

environment

temperature

humidity

Operating temperature:0to50degreesC Storage temperature:-20 to 70degreesC

5% to 90% no condensation

operating system

version

Android7.1/ Linux

AOS-SGR39216D1U

RK3399 2.0GHz 2G memory 16G EMMC

AOS-SGR39416D1U

RK3399 2.0GHz 4G memory 16G EMMC

AOS-SGR39432D1U

RK3399 2.0GHz 4G memory 32G EMMC
