chip set

SOC

BIOS

BaiAo supports features such as diskless startup, network wake-up, power-on startup, and watchdog.

internal storage

capacity

On-board LPDDR5/5X (available in 8GB, 16GB, or 32GB options)

memory

SATA interface

MSATA Interface

M.2 Interface

1x SATA 3.0, 6.0 Gb/s interface

1xmSATA,

1xM.2-KeyM/2280(PCIex4),

On-board eMMC

show

integrated graphics

output

VGA+HDMI

1 ¡Á VGA (Maximum supported resolution: 1920x1080)

1 ¡Á HDMI (Maximum supported resolution: 3840x2160 at 60 Hz)

network

Chip

2x10/100/1000M Adaptive

I/O

USB 2.0

USB 3.0

Power button

Reset

COM

LED lamp

DC JACK

audio frequency

debugging interface

expansion slot

electromagnetic compatibility

4x USB2.0

2¡Á USB3.0

1 ¡Á power button

1 ¡Á Reset

6xRS232 (2x16PIN, 2.0 pitch), with 2 optional 485 or 8xRS232 ports

           Red power indicator light, green hard drive indicator light

1 ¡Á DC JACK

1 x Line Out, 1 x MIC-in (built-in amplifier: 4/8¦¸,2 x 5W)

DEBUG(3.3V-TTL)+JTAG

1x M.2-KeyB/3050 (with 1x SIM card slot), 1x M.2-KeyE/2230 (Ö§³Ö Bluetooth/Wifi connectivity)

classs B

source

import

DC12V input

watchdog

output

margin

Interrupt, system restart

Level 255 Fixed Time Interval

Physical Parameter

size

205mm (L) x 160mm (W) x 88mm (H)

environment

temperature

temperature

humidity

Operating temperature: 0¨C50¡ãC (wide temperature range available)

Storage temperature: -40¡ãC to 85¡ãC

0¨C95% RH, non-condensing

operating system

edition

Ubuntu/Linux/Baidu Kirin/Zhongke Fangde/CentOS

AOS-SEZD3M81SY

D3000M memory: 8GB; SSD: 128GB

AOS-SEZD3M162SY

D3000M memory: 16GB; SSD: 256GB

AOS-SEZD3M325SY

D3000M memory: 32GB; SSD: 512GB
