Chipset

Intel® H110/Q170/C236

BIOS

AMI 32Mbitsupports diskless startup, network wake-up, power-on power-on, watchdog, and more

memory

capacity

4GB DDR4 2133/2400 MHz memory , Max.64GB

storage

SATA interface

SAS interface

M.2 interface

1*SATA

6 x SAS (supports 24 x SATA 3.0).

1*M.2 2280

display

Chipset

output

CPU integrated graphics card HD Graphics

VGA-HDMI-DP single- , dual-display, three-screen (same/asynchronous display). , /

1 × VGA (maximum support resolution:1920×1080).

1 ×HDMI (maximum support resolution:3840x2160 30HZ).

1 ×DP (maximum support resolution:3840x2160 60HZ).

Internet

chip

WIFI/3G/4G

3 × INTEL I211AT 10/100/1000M（RJ45 LAN）

1 x WIFI Module support 802.11b/g/n （M.2 PCIE half card）

I/O

USB 3.0

USB 2.0

PS/2

COM port

audio

4x USB3.0

4× USB2.0

1 × PS/2 keyboard mouse

2 × COM interface with an optional set of VGAs

1 × LINE-OUT and MIC-IN and 1x LINE IN,integrating 6-channel hi-fi sound

On-board functionality

COM port

USB2.0

USB3.0

PLT

FP

LED

EDP

SPK

PCIE

12*RS232+2*RS485

4*USB2.0

2*USB3.0

1 x PLT printout

1*FP

1*SAS LED

1*EDP

1*SPK

1*PCIE3.0 X16

1*MINI PCIE

power supply

input

Rated power consumption

ATX 1*24Pin +1*8Pin

600W

Watchdog

output

interval

Interruption, system restart

255-level timing interval

The physical parameters

size

482.53mm (L) x 176.5mm (W) x 504mm (H)

environment

temperature

humidity

Operating temperature:0to50degreesC Storage temperature:-20 to 70degreesC

5% to 90% no condensation

operating system

version

Windows 10/Windows 7 / windows8 / Linux

AOS-SSH11C41S24HU

Intel Celeron G3900 2.8GHz 4G memory 128G SSD

AOS-SSH11D41S24HU

Intel Pentium G4400 3.3GHz 4G memory 128G SSD

AOS-SSH11I41S24HU

Intel Core i3-6100 3.7GHz 4G memory 128G SSD

AOS-SSH11F41S24HU

Intel Core i5-6500 3.2GHz 4G memory 128G SSD

AOS-SSH11J41S24HU

Intel Core i7-6700 3.4GHz 4G memory 128G SSD
