chip set

Intel® SOC

BIOS

AMI 32Mbit, supporting diskless boot, network wake-up, power-on startup, watchdog, and other functions

internal storage

capacity

4GB SO-DIMM 2xDDR4 2400 MHz memory ,  Max.64GB

memory

SATA interface

M.2

2.5-inch HDD (optional)

1Xm.2 NGFF/NVME

show

Integrated Graphics

output

CPU-integrated graphics card: Graphics for 12th Gen/Iris Xe

4* HDMI + DP: single display, dual displays, or triple displays (ͬ²½/asynchronous/tiled display modes)

1 ¡Á HDMI 2.0 (Maximum supported resolution: 4096x2304 at 60 Hz)

1X DP1.4 (Supports resolutions: 4096*2304,5120*2880,7680*4320 at 60 Hz) 4K/5K/8K

LVDS/EDP

network

Chip

WIFI

4 ¡Á 10/100/1000M (optional 4*RJ45)

1 x WIFI Module support 802.11b/g/n £¨M.2 PCIE half card£©

I/O

USB2.0

GPIO

Mini-DP

RJ45

Power button

COM

LED lamp

Reset

One-click restoration

DC

audio frequency

4x USB 2.0 (up to 8 groups optional)

1x GPIO

1x Mini-DP

4¡ÁRJ45 (2x 1000M Ethernet ports + 2x 2.5G Ethernet)

1 ¡Á power button

6¡Á RS232 COM

            1 x power indicator light & 1 x hard drive indicator light

           1 ¡Á Reset button

1 x One-click restore

1 ¡Á DC JACK

1 ¡Á LINE-OUT &  MIC-IN

source

import

rated dissipation

DC 12¨C19V (optional wide-voltage input of 9¨C36V)

45-90W

watchdog

output

margin

Interrupt, system restart

Level 255 Fixed Time Interval

Physical Parameter

size

224mm (L) x 117mm (W)x67mm(H)

environment

temperature

humidity

Operating temperature: 0¡ãC to 50¡ãC   Storage temperature: -20¡ãC to 70¡ãC

5%~90% no condensation

operating system

edition

Windows 10/Windows 11 / Linux

AOS-SEN10414DL4DC

CPU: N100; 4GB RAM; 128GB SSD

AOS-SEN15041S4DL4DC

CPU: N150; 4GB RAM; 128GB SSD

AOS-SEN9741S4DL4DC

CPU: N97; 4GB RAM; 128GB SSD

AOS-SEN9541S4DL4DC

CPU: N95; 4GB RAM; 128GB SSD

AOS-SEN10541S4DL4DC

CPU: N105; 4GB RAM; 128GB SSD

AOS-SEN20041S4DL4DC

CPU: N200; 4GB RAM; 128GB SSD

AOS-SEN30041S4DL4DC

CPU: N300; 4GB RAM; 128GB SSD

AOS-SEN30541S4DL4DC

CPU: N305; 4GB RAM; 128GB SSD
