AOS-SSH51J162S4U
Product introduction£º
Specifications
processor
| CPU | Support Intel LGA1200 (Gen10&11 i9/i7/i5/i3/G series CPU TDP up to 125W) /I7 10700 (2.9GHz/8 cores/16MB/Core Graphics 630/14nm/65W |
chipset | Intel® H510/B560/W580 | |
BIOS | AMI 32Mbit£¬Support diskless boot, network wake-up, power-on boot, watchdog and other functions | |
Memory
| capacity | 4*DDR4 16GB , MAX 64G |
storage
| SATA interface M.2 interface | 2*SATA 1*M.2 256G SSD |
show
| Chipset Output
| HDMI+VGA+DP single display, dual display (synchronous/asynchronous display) 1 ¡Á HDMI (maximum supported resolution: 3840x2160 30HZ) 1 ¡Á DP (maximum supported resolution: 3840x2160 60HZ) |
network
| Chip WIFI/3G/4G | 2 ¡Á 10/100/1000M£¨RJ45 LAN£© 1 x WIFI Module support 802.11b/g/n £¨M.2 PCIE half card£© |
I/O | USB 3.0 USB 2.0 PS/2 COM port Audio | 4x USB3.0 4¡Á USB2.0 1 ¡Á PS/2keyboard mouse 1 ¡Á COM port 1 ¡Á LINE-OUT & MIC-IN & 1x LINE IN, integrated 6-channel high-fidelity sound |
Onboard functions
|
COM port USB2.0 ESPI interface TPM/TCM interface GPIO I²C/SM bus PCIE |
6*COM (COM1 supports RS232/485, COM2-6 supports RS232), 2*USB2.0 4 RS422 or RS485 can be expanded (optional) Onboard encryption chip SLB9670 (SLB9672) supports TPM2.0 (default) / BOM optional TCM chip 8-bit digital I/O, providing power and ground, +5V level One 4Pin I²C Bus interface (optional) 1*PCIE3.0 X16 |
power supply
| Input Rated power consumption | ATX 1*24Pin (supports ATX/AT power on/off mode) 300W |
watchdog
| output interval | Interrupt, system restart 255 level timer interval |
|
| 482mm (L) x 450mm (W) x 176mm (H) |
environment | temperature humidity | Operating temperature: 0¡ãC ~50¡ãC Storage temperature: -20~70¡ãC 5%~90% non-condensing
|
operating system | Version | Windows 10/Windows 11 / Linux |
Ordering information
Sales model | illustrate |
AOS-SSH51J162S4U | Intel Core i7-10700 2.9GHz 16GMemory 250G SSD |
AOS-SSH51I81S4U | Intel Core i3-10100 3.6GHz(4 cores) 8GMemory 128G SSD Intel Core i3-11100 3.8GHz(4 cores) 8GMemory 128G SSD |
AOS-SSH51F81S4U | Intel Core i5-10400 2.9GHz(6 cores) 8GMemory 128G SSD Intel Core i5-11400 2.6GHz(6 cores) 8GMemory 128G SSD |
AOS-SSH51J81S4U | Intel Core i7-10700 2.9GHz(8 cores) 8GMemory 128G SSD Intel Core i7-11700 2.5GHz(8 cores) 8GMemory 128G SSD |
AOS-SSH51X81S4U | Intel Core i9-10900 2.8GHz(10 cores) 8GMemory 128G SSD Intel Core i9-11900 2.5GHz(8 cores) 8GMemory 128G SSD |
Application areas
Applicable to education, restaurants, hotels, shopping malls, company meetings, government affairs disclosure and other fields.
Dimensional drawing
