AOS-SXH5I45B
Product introduction：
Specifications
processor | CPU | Intel Intel Core Core i3-2310M (dual-core quad-thread /2.1GHz/3MB three-level cache /HD3000/32nm/35W). |
Chipset | Intel® HM65 | |
BIOS | AMI 32Mbitsupports diskless startup, network wake-up, power-on power-on, watchdog, and more | |
memory | capacity | 4GB SO-DIMM DDR3 1333 MHz memory , Max.8GB |
storage | SATA interface MINI PCIE | 2.5〞5400rpm 500G 1xMini PCIE |
display | Chipset output
| CPU integrated graphics card HD Graphics VGA-HDMI/DP single-display, dual-display / display). 1 × VGA (maximum support resolution:1920×1080). 1 ×HDMI (maximum support resolution:1920x1080). 1 ×DP (maximum support resolution:1920x1080). |
Internet | chip WIFI | 1 × RTL8111E 10/100/1000M（RJ45 LAN） 1 x WIFI Module support 802.11b/g/n （Mini PCIE half card） |
I/O | USB 3.0 USB 2.0 COM RESET Power button LED light DC JACK audio | 2x USB3.0 5× USB2.0 1 ×COM(RS232)option 1 × Reset button 1 × power button 1 x Power indicator light . . . 1x hard drive indicator light 1 × DC JACK 1 × LINE-OUT and MIC-IN with integrated 6-channel sound ALC662 sound card chip |
power supply | input Rated power consumption | DC 12~19V 60W |
Watchdog | output interval | Interruption, system restart 255-level timing interval |
The physical parameters | size | 180mm (L) x 206mm (W) x 38mm (H) |
environment | temperature humidity | Operating temperature:0to50degreesC Storage temperature:-20 to 70degreesC 5% to 90% no condensation |
operating system | version | Windows xp/Windows 7 / windows8 / Linux |
Order information
Sales model | illustrate |
AOS-SXH5D45B | Intel Pentium B950 2.1GHz 4G memory 500G hard drive |
AOS-SXH5I45B | Intel Core i3-2310M 2.1GHz 4G memory 500G hard drive |
AOS-SXH5F45B | Intel Core i5-2520M 2.5GHz 4G memory 500G hard drive |
AOS-SXH5J45B | Intel Core i7-2620M 2.7GHz 4G memory 500G hard drive |
Applications
Suitable for education, restaurants, hotels, shopping malls, corporate meetings, government affairs and other fields.
Dimensions
