chipset

Intel® SOC

BIOS

AMI 32Mbit£¬Supports disk-free startup, network wake up, power-on, and watchdog functions

Internal memory

capacity

4GB SO-DIMM 2xDDR4 2400 MHz memory ,  Max.64GB

store

SATA interface

M.2

2.5¨•HDD(selectable)

1Xm.2 NGFF/NVME

reveal

Collective display

exportation

CPU integrated Graphics for 12th Gen /Iris Xe

4*HDMI+DP single display, double display, three display, four display (same/asynchronous/splicing display)

1 ¡ÁHDMI2.0 (Max support resolution: 4096x2304 60HZ)

1X DP1.4 (supported resolution: 4096*2304, 5120*2880, 7680*4320 60HZ)4K/5K/8K

LVDS/EDP

network

Chip

WIFI

1 ¡Á 10/100/1000M(¿ÉÑ¡2*RJ45)

1 x WIFI Module support 802.11b/g/n £¨M.2 PCIE half card£©

I/O

USB 3.1

Type-c

Power button

OPS port

  COM

LED light

One-button restoreDC JACK

Audio frequency

4x USB3.1

1x  type-c(selectable RJ45 LAN)

1 ¡Á power button

1 x OPS interface (80pin)

1 x RS232 COM (optional)

1x power indicator &1x hard disk indicator

1 x hardware system restore in one touch

1 ¡Á DC JACK

1 ¡Á LINE-OUT &  MIC-IN

Power source

input

Rated power consumption

DC  12~19V

45-90W

Guard dog

exportation

interval

The system restarts. Procedure

255 level timing interval

Physical parameter

dimension

180mm (L) x 119mm (W)x30mm(H)

environment

temperature

humidness

Operating temperature: 0¡ãC ~50¡ãC Storage temperature: -20 ¡ãC ~70¡ãC

5% to 90% no condensation

Operating system

edition

Windows 10/Windows 11 / Linux

AOS-SDAUI41S4D

Intel I3 1215U   1.2GHz    4Gmemory      128G SSD

AOS-SDAUF41S4D

Intel I5 1240P   1.7GHz    4Gmemory      128G SSD

Intel I5 13450H            4Gmemory      128G SSD

AOS-SDAUJ41S4D

Intel I7 1260P   2.1GHz    4Gmemory      128G SSD

Intel I7 13620H            4Gmemory      128G SSD
