chip set

Intel® SOC

BIOS

AMI 32Mbit, supporting diskless boot, network wake-up, power-on startup, watchdog, and other functions

internal storage

capacity

4GB SO-DIMM 2xDDR4 2400 MHz memory ,  Max.64GB

memory

SATA interface

M.2

2.5-inch HDD (optional)

1Xm.2 NGFF/NVME

show

Integrated Graphics

output

CPU-integrated graphics card: Graphics for 12th Gen/Iris Xe

2* HDMI  (ͬ²½/Òì²½/vid¨¦o wall display)

1 ¡Á HDMI 2.0 (Maximum supported resolution: 4096x2304 at 60 Hz)

1X DP1.4 (Supports resolutions: 4096*2304,5120*2880,7680*4320 at 60 Hz) 4K/5K/8K

LVDS/EDP

network

Chip

WIFI

1 ¡Á 10/100/1000M (2*RJ45 ports optional)

1 x WIFI Module support 802.11b/g/n £¨M.2 PCIE half card£©

I/O

USB 3.1

USB2.0

Type-c

Power button

COM

LED lamp

One-click restoration

DC JACK

audio frequency

4x USB3.1

2X USB2.0

1x Type-C (optional)

1 ¡Á power button

1 ¡Á RS232 COM (2 sets optional)

            1 x power indicator light & 1 x hard drive indicator light

            1 x One-click restore of the hardware system

1 ¡Á DC JACK

1 ¡Á LINE-OUT &  MIC-IN

source

import

rated dissipation

DC  12~19V

45-90W

watchdog

output

margin

Interrupt, system restart

Level 255 Fixed Time Interval

Physical Parameter

size

211mm (L) x 120mm (W)x38mm(H)

environment

temperature

humidity

Operating temperature: 0¡ãC to 50¡ãC   Storage temperature: -20¡ãC to 70¡ãC

5%~90% no condensation

operating system

edition

Windows 10/Windows 11 / Linux

AOS-SIAUI41S2D

Intel I3 1215U,1.2 GHz, 4 GB RAM, 128 GB SSD

AOS-SIAUF41S2D

Intel I5 1235U,4GB RAM, 128GB SSD

  Intel I5 1235U,4GB RAM, 128GB SSD

Intel I5 1240P,1.7 GHz, 4 GB RAM, 128 GB SSD

Intel I5 13450H processor, 4GB RAM, 128GB SSD

 Intel I5 13450H processor, 4GB RAM, 128GB SSD

AOS-SIAUJ41S2D

Intel I7 1260P,2.1 GHz, 4 GB RAM, 128 GB SSD

Intel I7 13620H processor, 4GB RAM, 128GB SSD

     Intel I7 13620H processor, 4GB RAM, 128GB SSD
