AOS-SIN1041SBMC2



Product introduction£º
Product introduction
Mini PC, Small Host
Supports AlderLake-N N100/N95/N97 CPUs
Supports 6 USB ports (4 USB 3.0 / 2 USB 2.0)
Supports 2 Intel i225/i226 2.5G Ethernet ports
HDMI 4K 60Hz display
Supports Wake-on-LAN, Power-on, Watchdog Timer, etc.
Complies with CE, FCC, and ROHS regulations
Dimensions: 135mm x 127mm x 39mm
Specifications
Cpu | CPU | Intel Alder Lake-N N100 0.8GHZ 4 Core TDP 6W |
chipset | Intel® SOC | |
BIOS | Supports disk-free startup, network wake up, power-on, and watchdog functions | |
Memory | Capacity | 4GB SO-DIMM DDR4 2400MHz memory , Max.32GB |
Storage | SATA port M.2 | 1*SATA 128G SSD 2280 NVME/NGFF |
Disply | GPU output
| CPU Integrated HD Graphics 2 ¡ÁHDMI£¨max£º3840x2160HZ£© 1 ¡ÁVGAdisply port£¨Choice DP£©
|
Internet | LAN WIFI | 2¡Á 1000M RJ45 1 x WIFI Module support 802.11b/g/n |
I/O | USB 3.0 USB 2.0 Power button Reset COM LED DC JACK Audio | 4x USB3.0 2¡Á USB2.0 1 ¡Á power button 1 ¡Á Reset button 2 ~ 4 ¡Á COM£¨choice£© 1 x power light&1xHDD light 1 ¡Á DC JACK 1 ¡Á LINE-OUT & MIC-IN £¬Integrated 6 channel sound ALC662 audio chipset. |
Power | input Rated power | DC 12V 60W |
Watch dog | output interval | interrupt¡¢system rastart 255time interval |
Physical | Dimension | 136mm (L) x 127mm (W)x40mm(H) |
Environment | Temperature Humidity | Working Temp£º0¡ãC ~50¡ãC Storage Temp£º-20~70¡ãC 5%~90% No Condensation |
Operating System | Version | Windows 10/11/Linux |
Ordering information
Sales Model | Specification |
AOS-SIN1041SBMC2 | Intel Celeron N100 0.8 GHz 4G Memory 128G SSD |
AOS-SIN15041SBMC2 | Intel Celeron N150 4G Memory 128G SSD |
AOS-SIN30541SBMC2 | Intel Celeron N305 4G Memory 128G SSD |
AOS-SIN9541SBMC2 | Intel Celeron N95 4G Memory 128G SSD |
AOS-SIN9541SBMC2 | Intel Celeron N97 4G Memory 128G SSD |
Areas of Application
Applicable to education, restaurants, hotels, shopping malls, companymeetings, government affairs disclosure and other areas.
