Chipset

Intel® H310

BIOS

AMI 32Mbitsupports diskless startup, network wake-up, power-on power-on, watchdog, and more

memory

capacity

4GB SO-DIMM DDR4 2400MHz memory , Max.32GB

storage

M.2 interface

SATA interface

MINI PCIE

128G SSD NGFF/NVME

HDD is optional

1X M.2 Mini PCIE

display

Stand-alone graphics output

Stand-alone graphics cards are available in both models and display output channels

HDMI-HDMI-DP single- , dual-display, three-screen (same/asynchronous display). , /

1 × HDMI (maximum support resolution:3840x2160).

1 ×HDMI (maximum support resolution:3840x2160).

1 × DP (maximum support resolution:3840x2160).

GTX730 2GB( HDMI/HDMI)

GTX1030 2GB(HDMI/DP)

GTX1050 2GB(HDMI/HDMI/DP)

GTX1050TI 4GB(HDMI/HDMI/DP)

GTX1060 6GB(HDMI/HDMI/DP)

GTX1070 8GB(HDMI/HDMI/DP)

GTX2080 8GB(HDMI/HDMI/DP)

Internet

chip

WIFI

1 × RTL8111H 10/100/1000M（RJ45 LAN）

1 x WIFI Module support 802.11b/g/n （M.2 half card）

I/O

USB 3.0

Type-c

COM

Power button

Reset

OPS interface

LED light

DC JACK

One-click restore

audio

6× USB3.0

1x Type-c

1x COM is optional

1 × power button

1 × Reset button

1 × OPS interface(80pin).

1 x Power indicator light . . . 1x hard drive indicator light

1 × DC JACK

1 x one-click restore

1 × LINE-OUT and MIC-IN with integrated 6-channel sound ALC662 sound card chip

power supply

input

Rated power consumption

DC 12~19V

90-200W

Watchdog

output

interval

Interruption, system restart

255-level timing interval

The physical parameters

size

180mm (L) x 195mm (W) x 30mm (H)

environment

temperature

humidity

Operating temperature:0to50degreesC Storage temperature:-20 to 70degreesC

5% to 90% no condensation

operating system

version

Windows 10/ Linux

AOS-SOH31C41S7GE

Intel Celeron G4900 3.1GHz 4G memory 128G SSD GT730 2G unique

AOS-SOH31D41S3GE

Intel Pentium G5400 3.7GHz 4G memory 128G SSD GT1030 2G stand-alone

AOS-SOH31I41S3GE

AOS-SOH31I41S5GE

Intel Core i3-8100 3.6GHz 4G memory 128G SSD GT1030 2G stand-alone

Intel Core i3-9100 3.6GHz 4G memory 128G SSD GT1050 2G stand-alone

AOS-SOH31F41S3GE

AOS-SOH31F41S5GE

Intel Core i5-8400 2.8GHz 4G memory 128G SSD GT1030 2G unique

Intel Core i5-9400 2.9GHz 4G memory 128G SSD GT1050 2G unique

AOS-SOH31J41S5IGE

AOS-SOH31J41S5IGE

Intel Core i7-8700 3.2GHz 4G memory 128G SSD GT1050TI 4G stand-alone

Intel Core i7-9700 3.0GHz 4G memory 128G SSD GT1050TI 4G unique

AOS-SOH31I41S6GE

AOS-SOH31F41S6GE

AOS-SOH31J41S6GE

Intel Core i3-9100F 3.6GHz 4G memory 128G SSD GT1060 6G unique

Intel Core i5-9400F 2.9GHz 4G memory 128G SSD GT1060 6G stand-alone

Intel Core i7-9700F 3.0GHz 4G memory 128G SSD GT1060 6G is unique
