AOS-SDMSIGC
Product introduction：
Specification
Features | Supports UTP protocol, can be networked for transmission, and the transmission distance can reach 20 kilometers | |
Supports receiving, encoding and decoding audio and video signals and COM control signals | ||
Display | input
| Supports video image resolution 1920*1080P Supports SDI input format (all formats, any SDI format) SD:525I@59.94HZ,625I@50HZ HD:720P@50HZ/59.94HZ/60HZ;1080I@50HZ/59.94HZ/60HZ; 1080P@23.98HZ/24HZ/35HZ/29.97HZ/30HZ 3G:1080P/50HZ/59.94HZ/60HZ |
Functions | COM port | 1X RS232+1X RS485 |
I/O | SDI
OPS interface LED light DC JACK | 3× SDI IN 1x SDI OUT 1 × OPS interface (80pin) 1 x LED indicator light 1 × DC JACK |
Power | Input Rated power consumption | DC 12~19V 30W |
Physical parameters | Dimensions | 175mm (L) x 110mm (W) |
Environment | Temperature Humidity | Operating temperature: 0°C ~50°C Storage temperature: -20~70°C 5%~90% non-condensing |
Area of application
Suitable for education, restaurants, hotels, shopping malls, corporatemeetings, government affairs and other areas.
