AOS-OPSC2A
Product introduction：
Product introduction
USB2.0 ports
1 USB3.0 port
2 USB2.0 pins
HDMI+DP output
Support RS232 COM port
Configured with standard Audio port (LINE-OUT)
Product complies with EU ROHS standards
Dual power input - 12V~19V input
Specifications
show | output | 1 ×HDMI 1 × DP
| ||
I/O | USB 2.0 USB 3.0 COM
J-SW1 J-SW2 Power button OPS interface Audio J-USB2.0 | 3× USB2.0（3 rear USB2.0 ports）， 1个USB3.0（optional） 1×JUART1（4pin Pin, 2.0 pitch, signal definition：VCC(5V) GND U-TX U-RX） 1×COM1（4pin Pin, 2.0 pitch，RS232 COM口） 1× switch pin（Signal Definition：PS-ON，GND） 1×power on detection pin (3pin, Signal Definition： PWR-Status GND PS-ON) 1 ×Power button (switch) OPS 80 pin 1 × LINE-OUT 3.5 standard interface, supports dual-channel output 1 × USB2.0 pin, can expand two USB2.0； | ||
power supply | Input | DC JACK (19V, 2.5mm inner diameter) Onboard 4pin socket （12 ～ 19V） | ||
Physical parameters | size | Thin Mini-ITX，133x44mm | ||
environment | Temperature Humidity | Operating temperature: 0°C ~60°C Storage temperature: -20~70°C 5%~90% non-condensing | ||
Ordering Information
Sales Model | illustrate |
AOS-OPSC2A | JAE OPS 80PIN,5 USB2.0,1 USB3.0,HDMI+DP display output+RS232 COM port |
Dimensions and Structure
