Chipset

SOC

Memory

Capacity

2GB SO-DIMM DDR3 1333 MHz memory ,   Max.4GB

Storage

EMMC

TF Card

M.2

32G,   Max.64GB

Support 64G

Support 128G

Display

Graphics

Output

CPU Integrated Graphics

HDMI+HDMI+LVDS

support one / twp displayer(s)

Synchronous / Asynchronous Display

1 × LVDS   （Max. Resolution: 1920x1080）

1 ×   HDMI   （Max. Resolution: 3840x2160）

Function

MINI PCIE

COM口

功放

1X MINI PCIE(3G/4G)

1X RS232+1X RS485

5W

Ethernet

Lan

WIFI

1 × RTL8211E   10/100/1000M（RJ45 LAN)

optional dual ethernet interface

1 x AP6356S AMPAK, Wi-Fi 2.4G/5G dual mode+BT

I/O

USB 2.0

IR

Power button

Reset

OPS Interface

LED Light

DC JACK

Audio

3× USB2.0 (Max. 3 pcs USB)

1x   USB3.0

1X IR

1 × power button

1 x Upgrade

1 × OPS Interface (80 pins)

1 x Power LED

1 × DC JACK

1 × LINE-OUT & MIC-IN, Integrated 6 sound channels ALC662 audio card chip

Power

Input

Rated Power

DC   12~19V

20W

Physical

Parameter

Dimension

180mm (L) x 119mm (W)x30mm(H)

Condition

Temperature

Humidity

Work Temp.: 0°C ~50°C, Storage Temp.: -20~70°C

5%~90% No condensation

Operating System

Vision

Android7.0/ /   Linux
